AutoCAD Civil 3D Outsource Service



Corridor Modelling

I can produce highly detailed road models, making full use of Civil 3D Corridors.  My road experience covers minor road layouts and access tracks. This includes wind farm access tracks with turbine hardstands.

Detailed Terrain Modelling

Have you received a detailed LIDAR, and need a 3D terrain model produced?  Send the source files to me and I can produce this with no problem.

Cut/Fill Volume Models

I can produce detailed cut/fill models that can make a real difference when deciding on the levels for your site. I can optimise your design to minimise unnecessary volumes of earth.

Pipe Networks

I can model dynamic detailed pipe networks for your scheme.  These can be used in 2D plans and on long sections for your Engineering drawing output.


More and more clients are asking for GIS deliverables from their Civil 3D models.  This is something Tech Drawing Ltd has experiencing, just let me know the SCHEMA parameters.

I can also integrate existing GIS data from your team to make modelling a lot more streamelined


Any models created in Civil 3D can be exported to Navisworks to coordinate with other disciplines within your project.



My name is Martin Wilson, I have 20 years experience working with various large multi-disciplinary engineering consultants and local authorities. This has allowed me to gain extensive experience in a wide array of disciplines. I have worked on myriad large scale projects (such as nuclear power stations and large wind farm designs), in addition to many more projects of varying sizes. I started using Civil 3D over 10 years ago, and have used it nonstop since, gaining a high level of expertise that I am eager to share with my clients.

Civil 3D is a very powerful civil design package, bringing civil engineering into the BIM (building information modelling) world.  Boosting productivity and quality on any infrastructure style project, this is a powerful tool in my arsenal of skills. Whether it be for road modelling, 3D terrain modelling, pipe networks, Cut/Fill Analysis, or other projects, I can help your company.

I offer my clients friendly, courteous and professional service. I can provide holiday cover for your projects, or if you are in need of staff for a project and you do not want or need to hire a permanent member of staff, you can send the work to me.

I am also happy to come into your office and provide ‘on the job’ support for your Civil 3D projects, giving your staff guidance on how to best use the software.



For any enquiries or questions, please fill out the following form
